Bendix Push/Pull Control Air Valve Assembly
BW 284726N Truck Push/Pull Control Air Valve Assembly
- Brand: Bendix
- A push-pull manually operable on-off air control valve with an exhaust function
- Works by controlling non-modulating air controlled devices in air brake systems
- Engineered using state-of-the-art technology for guaranteed efficiency even under extreme conditions
- Meets your vehicle's more stringent compressed air requirements
- All Bendix valves are designed to enhance and improve vehicle performance
- VMRS Code: 013010017
| Mounting Hardware Included | Yes |
| Mounting Hole Diameter | 7/8-20 in. UNEF-2A |
| Delivery Port Diameter | 1/8-27 in. NPT |
| Exhaust Port Diameter | 1/8-27 in. NPT |
| Maximum Operating Temperature | 200 °F (93 °C) |
| Minimum Operating Temperature | -40 °F (-40 °C) |
| New Or Remanufactured | New |
| Notes | Plunger/Button Height: 1.59 in.; Plunger Diameter: 0.374 in.; Diamond-Shaped, Yellow/Black Band Button; Button Text: Pull to Apply, Parking Brake, Push to Release |
| Release Pressure | 40 PS |
| Series | PP-1® |
| Supply Port Diameter | 1/8-27 in. NPT |
| Type | Push-Pull Style |
Part # BW 284726N
A part of the Knorr-Bremse Group, Bendix® provides the automotive and truck parts industry with cutting-edge energy management solutions, active safety technologies, and air brake charging for tractors, buses, commercial vehicles, trailers, as well as medium- and heavy-duty trucks throughout North America. Headquartered in Elyria, Ohio, Bendix Commercial Vehicle Systems employs over 3,200 people who work hand in hand for the accomplishment of the brand's vision: "to become the leading worldwide supplier of active vehicle safety systems within the commercial vehicle industry." This brand takes pride in being the first to introduce many notable parts and technologies to the North American commercial vehicle market. Among these many firsts are the groundbreaking air brake system technologies such as air dryers, air compressors, and ABS. At Bendix, exceeding industry standards is a strict requirement.
