Description
Freightliner Air Brake Chamber - LH | WAB 423 106 007 0
Features & Benefits
- Crafted using top-quality raw materials for durability
- Easy installation process
- Designed to meet or exceed OEM specifications
- Designed to withstand the harshest conditions
Product Attributes
Bolt Hole Center-to-Center Length - 4.75 in
Bolt Length - 1.54 in
Bolt Thread Size - 5/8-11 UNC in
Clevis Pin Diameter - 0.51 in
Max Operating Pressure - 116 psi
Max Pressure - 145 psi
Operation Type - Cam
Outer Diameter - 186 mm
Output Force - 1686.07 lbf.ft
Overall Length - 4.69 in
Port Thread Size - 3/8-18 NPTF in
Push Rod Length - 3.55 in
Push Rod Thread Size - 3/8 in
Spring Force - 39.34 lbf.ft
Stroke Length - 2.99 in
Type - 24
Version - W/O Boot
Weight 3.70 kg
Width 107 mm
Working Pressure - 116 psi
Working Temp. Range - -40 to +185 F
Yoke Included - Yes
