Description
Premier Manufacturing 2200ELL Slack Reducing Couplings
2200ELL Couplings
The 2200ELL Coupling Is The Perfect Combination Of The 2200EL (2200 With The Extended Life Latch System) And Our Low Profile Lever Components. The Low Profile Lever Is A Good Option For Latch Clearance Issues And Ease Of Use. Please Note The Low Profile Lever Is Only Available With The 2200 Coupling. This Coupling Offers A Maximum Gross Trailer Weight Of 100,000 Lbs. And 60,000 Lbs. Latch Capacity, Making It Perfect For Heavy-Duty Applications.
- Brand: Premier Manufacturing
- Legacy # 2200ELL
- Dimensions: 11.18 X 7.03 X 8.375, 29.6 LBS.
- Heavy Duty
- Slack Reducing
- Premalloy
- Extended Life
Available Models:
| Model # | Part # | Description |
| 2200ELL | 10004696 | 2200EL Coupling with a 2075 Low Profile Lever installed & 271 Thimble |
| 2200ELLA | 10004698 | 2200EL Coupling with a 2075 Low Profile Lever installed, 501 Bolt Kit, 281 Air Chamber, 267 Air Chamber Adapter Bracket, 271 Thimble |
Kit Components & Accessory Parts:
| Model # | Part # | Description |
| 271 | 10000107 | Thimble |
| 501 | 10000149 | Bolt Kit |
| 281 | 10000116 | Air Chamber, Type 24 |
| 282 | 10000122 | Air Chamber, Type 30 |
| 267 | 10000098 | Air Chamber Adapter Bracket (2 3/4 in. overall length) |
| 267F | 10000101 | Air Chamber Adapter Bracket (4 5/8 in. overall length |
| 267H | 10000102 | Air Chamber Adapter Bracket (3/4 in. overall length) |
| 2200PK-ELL | 10000262 | Parts Kit, Extended Life (EL), Low Profile Lever |
| 438 | 10004779 | Drawbar Guide Set (Left & Right Sides Incl.) |
| 438L | 10000131 | Drawbar Guide, Left Side Only |
| 438R | 10000133 | Drawbar Guide, Right Side Only |
| 14014 | 10000062 | Wear Gage |
| 14026 | 10000071 | Wear Gage, Latch Gage Bar |
Part # 10004696 & 10004698
